RISE BEYOND

Rise is a machine designed to expand your trail experience and bring you closer to the moment.

Rise brings you nearer the sensation that less “e” delivers more “bike”. Whether you crave riding greater distances, reaching more epic locations, improving efficiency or increasing the frequency of your adventures, Rise beyond expectations and discover the new standard in MTB.

Rider Synergy Concept

• RS is a new philosophy – a completely integrated system that becomes a reality when Power, Range, Interface and Weight are considered together.
• A new riding experience that enhances the joy of traditional trail riding with smooth support that feels as natural and alive as your own body.
  Minimalist, integrated and sleek with no bulky components to take you out of the moment, bringing you closer to the trails and the ride. An ebike designed specifically for the trail rider.

RS Power - Creating the concept with Shimano

• The idea of creating our own power plant for Rise was daunting, but we believed that this would be the only way to realize our goal of a complete RS system for trail bikes.
• We had been looking for the best way to achieve this for a long time, so when Shimano shared the plans for their new EP8 motor, we quickly realized that this awesome drive unit offered us the perfect platform on which to build the RS Power concept.
• Max speed: 25km/h
• Max torque: 60nm
• Weight: 2.6kg

RS Range
Rise is intended for big rides. Rise features a modular battery solution that provides up to 612wh, combining a very light and compact 360wh main battery integrated in the down tube with a patent-pending 252Wh range extender.

Main battery:

• 360Wh
• 2.2kg
• Over 4hrs ride time

RS Range Extender:

• 252Wh
• 1.4kg
• Extra 70% ride time

RS Interface - Sleek and expandable

• We have embraced data collection with computers and smartphones but often stop short of attaching large displays on our handlebars or top tubes.
• Switch & EW-EN100.
• RS Garmin IQ

RS Weight

• The RS Motor, Battery and Electronics are lighter than other eBike systems by over half. Rise can weight as little as 16.5 kg or 36.3 lbs.
• The beauty of the RS system is that assistance torque and power is provided within a range where normal, high-quality trail bike components can be used.
• OMR Frame
• 2300g without shock

Features:

• Carbon frame
• Fox 36 Float Factory 150 Grip2
• Fox FLOAT X Factory 2-Position Evol LV
• Shimano XTR 12sp w/ Shimano Steps EM900 crankset
• Shimano XTR M9120 Hydraulic Disc Brakes

• Race Face TURBINE-R30
• Fox Transfer Factory Kashima Dropper
• Shimano EP8-RS motor

• Orbea RS Internal 360Wh battery
